Maier |
 |
|
|
Rotary Joint-DQ Series |
 |
|
Application Data |
|
DQL |
|
DQ |
|
DQT |
|
DQTX |
|
|
|
|
|
Design
Nominal diameter DN mm |
1, B2
25-150 |
1, B2
25-150 |
1, B2
25-150 |
1, B2
25-150 |
|
|
|
|
|
Additional device for
cooling and lubrication |
- |
KE, KEW |
KE, KEW |
KE, KEW |
|
|
|
|
|
Medium |
thermal oil |
thermal oil |
thermal oil |
thermal oil |
|
|
|
|
|
Temperature
max-゜C
max-゜F |
250
482 |
300
572 |
350
662 |
400
752 |
|
|
|
|
|
Pressure PN
max-Bar
max-psi |
10
145 |
10
145 |
10
145 |
10
145 |
|
|
|
|
|
Speed
max-min–1 |
35000*
DN |
55000
DN |
55000
DN |
55000
DN |
|
|
Rotary Joint –DP Series |
 |
|
Application data |
|
DP |
|
DP |
|
DP-800 |
|
|
|
|
Nominal diameter DN mm |
03...06 |
10...50 |
10...50 |
|
|
|
|
Medium |
compressed air
cooling water
hot water |
cooling water
hot water |
thermal oil |
|
|
|
|
Temperature min:max-゜C
Pressure PN min:max-bar |
...120
...10 |
-15...160
0,2...10 |
...160
...10 |
|
|
|
|
压力PN
最高Bar
最高psi |
10
145 |
10
145 |
10
145 |
|
|
|
|
Speed
max-min–1 |
55000/DN
3000 |
55000/DN
2500 |
55000/DN
2500 |
|
|
Rotary Joint-DX Series |
 |
|
Application data |
|
DX |
|
DXS |
|
DXS |
|
DXS |
|
DXS-200 |
|
DXS-300 |
|
|
|
|
|
|
|
Version
Nominal diameter mm |
1, 2, R2
10...80 |
1, 2
10...80 |
R2
10...80 |
B2
50...80 |
1, 2, B2
100...150 |
1, 2, B2
100...160 |
|
|
|
|
|
|
|
Medium |
Cooling water |
Cooling water
Hot water |
Cooling water
Hot water |
Cooling water
Hot water |
Cooling water
Hot water |
Cooling water
Hot water |
|
|
|
|
|
|
|
Temperature
min-max゜C
Pressure PN
min-max bar |
-10...80
-0,2...8 |
-10...150
-0,2...8 |
-10...150
-0,2...8 |
-10...150
-0,2...8 |
-10...150
-0,2...8 |
-10...160
-0,2...16 |
|
|
|
|
|
|
|
Speed
max:min–1 |
50000
DN |
55000
DN |
50000
DN |
55000
DN |
DN100: 300
DN125: 300
DN150: 100 |
DN100: 600
DN125: 500
DN150: 400 |
|
|
|
|
Shanghai Fier Mechanical Co.,Ltd |
ADD:Room B4,15/F,HuaFu Building,No.585,LongHua Xi Rd,ShangHai Tel: +86 21 54591038 |
